Milling
VMC 1300 Pro: CNC Milling Machine
Powerful 3-axis CNC milling for education, engineering and technical training.
Price on application
This product is built to order and the quote can be customised to your specification.
Machine metals and more
Industrial CNC capability
Industrial-level CNC milling for education and training
The Denford VMC 1300 Pro is a powerful, fully enclosed 3-axis CNC milling machine designed for education and engineering training. Combining industrial-level machining capability with an education-ready format, it enables students and trainees to develop practical CNC machining and CAD/CAM skills using a wide range of materials.
With a high-speed 6,000 rpm spindle, the VMC 1300 Pro can machine materials including plastics, acrylic, aluminium, free-cutting alloys and steel.
FEATURES
Machine Aluminium, Steel and More
The VMC 1300 Pro is capable of machining a broad range of materials, allowing it to support everything from introductory CNC exercises to more demanding engineering projects.
Suitable materials include:
- Aluminium
- Steel
- Free-cutting alloys
- Acrylic
- Plastics
- Wax
The powerful high-speed spindle provides up to 6,000 rpm, while optional Flood Coolant or Spray Mist Coolant can support more demanding machining applications.
FEATURES
Who is the VMC 1300 Pro for?
The VMC 1300 Pro is designed for organisations looking to provide practical CNC machining and advanced manufacturing experience within a learning or training environment.
Schools and Sixth Forms
Introduce students to CNC machining, CAD/CAM, engineering and manufacturing processes using an education-focused CNC platform.
Further Education Colleges
Develop practical engineering and manufacturing skills alongside classroom learning and technical qualifications.
Universities
Provide CNC machining capability for teaching, student projects, prototyping, research and engineering applications.
Apprenticeship and Training Providers
Give apprentices practical experience of CNC programming, machine setup, CAD/CAM and component manufacture.
Engineering Training Facilities
Develop transferable CNC and manufacturing skills using industry-relevant machining processes and technology.
Technical information
Equipment as standard
- VR CNC Milling Operating Software (PC not included)
- QuickCAM 2D Design Software (1 seat)
- Power Drawbar with Manual Actuation
- Workholding Clamps
- Installation and Instruction Manuals
- Ethernet or USB Connection
- *PC Not included
NB The Flood Coolant model comes complete with Machine Bench
Optional extras
- Recommended Set of Tools
- Recommended Set of Toolholders
- Self-Centring Vice
- Table Mounted 6 or 8 Station Automatic Tool Changer (which can be removed to enable full 375mm X axis travel)
- Spray Mist Coolant
- Automatic Lubrication System
- 4th Axis Programmable Rotary Fixture (Inc. QuickCAM 4D, site licence) NB. Not available with flood coolant model.
- Machine Bench (flood coolant model comes as standard with machine bench)
- Computer Support Extension for Machine Bench.
- Pneumatic Vice
- Pneumatic Guarding
Mechanical details
| Machine Length | 1300mm (51.18in) |
| Machine Depth | 750mm (29.53in) |
| Machine Height | 1325mm (52.17in) |
| Length with Optional PC Arm | 1910mm (75.20in) |
| Machine Height with Optional Base | 1765mm (69.49in) |
| Machine Length with Optional Base | 1330mm (52.36in) |
| Additional Height Door Open | 65mm (2.56in) |
| Machine Weight | 353kg (778.22in) |
| Machine Weight with Optional Base | 456kg (1005.31in) |
| Table Size | 600 x 180mm (23.62x7.09in) |
| Table to Spindle | 305mm (12.01in) |
| Max Spindle Speed | 6000rpm |
| Max Feed Rate | 5000mm/min (196.85in/min) |
| Max 3D Profiling | 4500mm/min (177.17in/min) |
| Power Requirements | Single Phase. 230V - 10A / 110V - 16A |
| Spindle Motor | 1.1kW (1.38HP) 1.6kW (2.15HP) |
| Axes Motors | Stepper |
| Frequency | 50 / 60 Hz |
Downloads
Product Spec Sheet
VMC 1300 Pro
Download
198 KB | pdf
Software for the VMC 1300 Pro Milling Machine
All software required to control the VMC 1300 Pro is included with the machine.
VR CNC Milling
VR CNC Milling provides the interface for operating and controlling the VMC 1300 Pro.
The software can import DXF, DWG, EPS and Gerber files, as well as G & M code programs, allowing it to integrate with a range of design and manufacturing workflows.
QuickCAM 2D Design
A seat of QuickCAM 2D Design is included as standard.
This easy-to-use CAD/CAM package enables users to create 2D designs and generate machining data, making it particularly suitable for education and CNC training.
QuickCAM Pro
For users looking to machine components created using 3D design software, optional QuickCAM Pro enables STL files to be imported and cutter paths created for machining 3D parts.
QuickCAM 2D Design
QuickCAM 2D Design Software is an advanced, yet simple to use, wizard based 2D CAD/CAM package, which now includes V-Carve Extension as standard.
More Info
QuickCAM PRO
QuickCAM Pro is an advanced, yet simple to use, wizard based CAM package, which is used to create cutter paths for machining 3D parts on a milling machine or router.
More Info
